PE connection

DANGER

Danger to life from electrical shock!

In the event of an interruption to the PE connection, avoid touching the casing because life-threatening levels of voltage may be present!

Steps to prevent:

  • EN 61800-5-1 requires that the devices be firmly connected on the power side.
  • The PE conductor must have a cross-section of at least 10 mm2 or must have a second PE connection with a cross-section at least equal to the mains feeder (cf. EN 61800-5-1).
Cross-section AC wire Cross-section PE wire
≤ 10 mm2 = 10 mm2
10 ... 16 mm2 = Cross-section AC wire
16 ... 35 mm2 = 16 mm2
≥ 35 mm2 ≈ 1/2 x Cross-section AC wire



Description:

The PE connection is a screw bolt on the module casing (see front view) for attaching PE lines and cable shields.

Configure as follows:

Connection:

Recommended
cable type

1-wire, unshielded

Further information: Siehe 'Wiring'.

Cable assembly

Ring cable lug



Compact power supply

KEN 5, KEN 5-F

KEN 10, KEN 10-F

KE 10

KE 20-F

KE 20, KE 20-0EU

KES 20,

KES 20-0EU

KE 40, KE 40-0EU

KES 40-0EU

Recommended
wire cross-sections

10 mm²

AWG 6

16 mm²

AWG 4

Tightening torque

4 Nm

8 Nm

8 Nm

15 Nm



Compact power supply

KEN 60 (KE 60-S4)

KE 60, KE 60-0EU

KES 60, KES 60-0EU

KEN 120

KE 120, KE 120-0EU

KES 120, KES 120-0EU

KE 180, KE 180-0EU

KES 180, KES 180-0EU

Recommended
wire cross-sections

16 mm²

AWG 4

50 mm²

AWG 1/0

95 mm2
kcmil 250

Tightening torque

15 Nm

15 Nm

12 Nm

Note

Further information: Siehe 'Earthing'.
